0℃~1300℃ Alarm REX C100 Digital LED PID Temperature Controller

Temperature Controllers Specification: REX-C100 thermostat Model no. : rex-c100fk07-v *AN Measurement accuracy: 0.5% FS End to end compensation tolerance:±2 (can be modified by software in 0~50) Resolution: 14 bits Sampling cycle: 0.5 seconds Power supply: AC 110-240v 50/60hz Process value (PV), set value (SV) Output, alarm and self-setting can be indicated : by LED PIN control (including ON/OFF, stepper PID and continuous PID) Self-adjusting control Delayed output: contact capacity 250V AC 3A (resistance load) Alarm function output: 2 channels Proportional band (P) : 0 ~ full range (ON/OFF control set to 0) The testing temperature range: 0 ~ 1300 Insulation resistance: > 50M ohm (500V DC) Insulation resistance: 1500V AC/min Insulation resistance: power consumption The environment of service: 0 ~ 50 Non-corrosive gas environment 30 ~ 85% RH Appearance size: 48*48*110mm Package list: 1 x REX-C100 PID temperature controller(0-1300)
